Arrow Tank has the equipment needed to complete your project to the highest standards. We do our best to keep up with technology to give our customers the edge they need to compete in a world wide economy.

The Following Sizes & Weights Can be Utilized:
Plate Thickness:  10 Gauge through 10"
Diameter (Including shipping considerations):  18’-6" x 18’-6" Maximum
Length:  150’
Weight:  240-Ton





Mobile Yard Cranes

Qty.

Crane Capacity/Description

1

(1)

15-Ton Grove

2

(2)

25-Ton Terrex

3

(1)

180-Ton American 8470 Truck Crane

4

(1)

250-Ton American 9310 Crawler

Equipment

Type

Quantity

Capacity

Threaders

-

3

-

Power Saws

-

2

20"

Plate Shears

Mechanical

2

1/4" x 10’

Hydraulic Shears

Scissors

1

3/4" x 12’

Auto Flame Cutting

CNC Controlled

1

2 Torches

Plasma Arc Cutting

CNC Controlled

1

10 Gauge to 2-1/2"

Lathes

-

2

24" & 12" Swing

Welding

Various

170

Up to 1,000 Amps

Drill Presses

Radial

3

12" x 48"

Band Saws

CAD Controlled

1

18" x 24"

Pipe Benders

-

1

4" Pipe

Plate Rolls

Pinch Type/Description

Pinch 1

Davi 4" x 10’

Pinch 2

Bertsch  2" x 10’

Pinch 3

Bertsch  3/4" x 10’

Pinch 4

Bertsch  1/4" x 8’

Pinch 5

Wysong 10 Gauge x 6’

Brakes

Mechanical Type

Hydraulic Type

Qty.

2

1

Capacity

80-Ton, 200-Ton

500-Ton

Plate Widths

12’, 12’

18’

Capability

14 Gauge to 1"



Stress Relieving Furnace:

Localized      Heat      Treat      Capabilities

Furnace 1

Furnace 2

Furnace 3

Up to 200 tons of load at temp of 1700°F
Max temp from 300°F to 1700°F
State-of-the-art PLC controls
Independent 4-Zone temp control
Temperature uniformity of +/- 25°F
Up to 52 thermocouples (expandable)
32 million BTUH heating capacity
18’-0" dia x 74’-0" long
15’-0" square x 74’-0" long

Up to 80 tons of load at temp of 1350°F
Max temp from 300°F to 1350°F
State-of-the-art PLC controls
Independent 2-Zone temp control
Temperature uniformity of +/- 25°F
Up to 52 thermocouples (expandable)
16 million BTUH heating capacity
14’-0" dia x 31’-0" long
13’-6" square x 31’-0" long

Maximum 109’-6" long
Up to 280 tons of load at temp of 1350°F
Max temp from 300°F to 1350°F
State-of-the-art PLC controls
Independent 6-Zone temp control
Temperature uniformity of +/- 25°F
Up to 78 thermocouples (expandable)
48 million BTUH heating capacity
14’-0" dia x 109’-6" long
13’-6" square x 109’-6" long



Flanging Machine:
Manufacturer:  Blue Valley, 1" Capacity.

Angle Rolls:  5" x 5" x 1/2" Capacity.

Welding Equipment:
Current Range
(170) Welding Machines  300-1000 Amps
(25) Welding Positioners  to 25,000 Lbs.
 (48) Shell Turning Rolls  to 600-Tons
 (8) Manipulators   to 16’ High
 (4) Twin Wire Sub Arc  to 16’ High

Qualified Welding Procedures:  (American Welding Society Designations).
 Semi-Automatic:  SAW, GTAW
Manual:  SMAW, FCAW, GTAW, GMAW.

Non-Destructive Testing Equipment:  (All work done at Arrow Tank)
Radiography.
Magnetic Particle:  Fixed Straight Yoke AC, DC
Liquid Penetrant Inspection Equipment:
Ultrasonic Testing:  Shearwave & Straight Beam
Materials Testing Lab:   (Use Outside Source)
Hardness Testing:  Telebrinneller
Ferrite Testing: Fisher Ferrite Scope

Pressure Testing:
Air:  100 PSI
Hydrostatic:  3500 PSIG
 Digital Chart Recorder

Blast Facilities:
Grit Blast Booth:  24’ x 24’ x 96’ Long
 Four Pot Capacity with Cleaning and Reclaim Equipment
Staurolite & Glass Bead Blast Room:  30’ x 80’ Long for non-ferrous blasting

(2) Paint Booths:  24’ W x 23’ H x 83’ L and 28’ W x 24’ H x 100’ L.
Utilizing Air or Airless Electro-Static Equipment
 Digital Paint Thickness Gauge
 Digital Environmental Gauge
 Heat Cure Capable to 120°F in Booth
